JCC Toughbay Pro 200W / 150W / 100W LED Wattage Selectable High Bay 4000K
Part Code: JC040222
Stock Code: 2822-5459
JCC Toughbay Pro 200W / 150W / 100W LED Wattage Selectable High Bay 4000K
Part Code: JC040222
Stock Code: 2822-5459
Delivery
196 In Stock
Free delivery on orders over £50
£5.95 Delivery on orders under £50
Features
- Wattage selectable 200W, 150W and 100W LED high bay
- 120° degree beam angle
- 1-10V dimmable as standard
- Lumen outputs: 15350lm [100W], 21600lm [150W], 26200lm [200W]
- Cool white light [4000K]
- Simple tool free conversion to microwave dim or PIR dim sensing
- Ultra efficient, up to 150 lumens per circuit Watt
- Surface mount bracket also available [sold separately]
- Register with JCC within 6 months of purchase to extend warranty / guarantee from 2 years to 5 years with 1 year on-site
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Beam Angle
- 120°
- Class Type
- Class 1
- Colour
- Black
- Colour Rendering Index(Cri)
- 82
- Colour Temperature
- 4000 K
- Compliance
- UKCA, CE
- Diameter
- 290mm
- Dimensions
- (Dia)290 mm x (H)165 mm
- Dimmable
- Yes
- Emergency
- No
- Energy Saving
- Yes
- Finish
- Black
- Guarantee
- 2 Years
- Height
- 165mm
- IP Rating
- IP65
- Ik Rating
- IK10
- Lamp Life
- 60000h
- Lamp Type
- Integrated LED
- Lens Colour
- Clear
- Light Source Energy Rating
- C
- Lumens Output
- 15350lm 21600lm 26200lm
- Material
- Aluminium / Polycarbonate
- Maximum Operating Temperature
- 40°C
- Minimum Operating Temperature
- -20°C
- Mounting
- Ceiling / Suspended
- Packaging Types
- Each
- Power Rating
- 100W 150W 200W
- Product Range
- Toughbay Pro
- Standards
- BS 60598-1
- Unspsc V18
- 39111546
- Unspsc V24
- 39111546
- Voltage Rating
- 230V
- Weight
- 1.9kg
