Timeguard Slim Line 7 Day Fused Spur Timeswitch
Part Code: FST77SL
Stock Code: 2825-7313
Timeguard Slim Line 7 Day Fused Spur Timeswitch
Part Code: FST77SL
Stock Code: 2825-7313
Delivery
20 In Stock
Free delivery on orders over £50
£5.95 Delivery on orders under £50
Features
- Up to 8 ON and OFF programmes available [5 day plus 2 or 7 day programmes] giving up to 56 ON and OFF programmes per week
- Suitable for use with up to 3kW immersion heaters
- Red LED ‘Mains ON’ and green LED ‘Output’ indicators for easy viewing
- Permanent ON/ OFF and timed outputs available
- Easy view 24 hour digital clock/timer display
- Optional 30, 60, 90 and 120 minute boost facility
- Automatic summer/winter time changeover
- Self-cancelling override
- Programme advance and review options
- Integral memory back up battery retains programmes in event of power failure
- Ideal for replacing single gang connection unit or fixed appliance outlets [10mm spacer included]
- Single pole isolation switch for ease of control. BS1362 fuse replaceable from front
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Timeguard
- Battery Back Up
- Yes
- Boost
- 30 min or 2 hrs
- Colour
- White
- Current Rating
- 13A
- Depth
- 35mm
- Dimensions
- (H)85 mm x (W)85 mm x (D)35 mm
- Display Type
- Easy View 24 Hour Digital Clock/Timer Display
- Finish
- White
- Guarantee
- 3 Years
- Height
- 85mm
- Manual Override
- Yes
- Maximum Operating Temperature
- 40°C
- Minimum Operating Temperature
- 0°C
- Mounting
- Wall
- Neon
- Yes
- Number of On offs
- 28
- Number of Poles
- Double Pole
- Packaging Types
- Each
- Programming Type
- Digital
- Suitable For
- Replacing single gang connection unit or fixed appliance outlets
- Unspsc V18
- 39121523
- Unspsc V24
- 39121523
- Voltage Rating
- 230V
- Weight
- 0.21kg
- Width
- 85mm
