Timeguard 24 Hour / 7 Day Analogue Time Switch
Part Code: SYN269H
Stock Code: 0515-1643
Timeguard 24 Hour / 7 Day Analogue Time Switch
Part Code: SYN269H
Stock Code: 0515-1643
Features
- 1 Channel analogue time switch with daily or weekly program [switching disc can be turned]
- Without power reserve
- Synchronised with mains
- Switching preselection
- Permanent on/off switch
- Shortest switching time: 20 minutes or 2 hours
- Clock hands for time display
- Switching status display
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Timeguard
- Colour
- Grey
- Current Rating
- 10A
- Current Rating Inductive
- 2A
- Depth
- 69mm
- Dimensions
- (H)104 mm x (W)72 mm x (D)69 mm
- Display Type
- Segment
- Guarantee
- 1 Year
- Height
- 104mm
- Material
- Plastic
- Minimum Time Settings
- 20min
- Mounting
- Surface
- Override Switch
- Yes
- Packaging Types
- Each
- Programming Type
- Mechanical
- Standards
- EN 60 730-1
- Type
- Timeswitch
- Unspsc V18
- 39121523
- Unspsc V24
- 39121523
- Voltage Rating
- 230V
- Weight
- 0.24500kg
- Width
- 72mm
