Wago 6mm Standard DIN Rail Terminal Grey
Part Code: 2006-1201
Stock Code: 0975-4531
Wago 6mm Standard DIN Rail Terminal Grey
Part Code: 2006-1201
Stock Code: 0975-4531
Delivery
294 In Stock
Free delivery on orders over £50
£5.95 Delivery on orders under £50
Features
- 2 conductor through terminal
- Simple push-in termination of solid and ferruled conductors
- Pushbutton operation for connection of stranded conductors
- Suitable for railway, transporation, marine and hazardous areas
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Wago
- Colour
- Grey
- Current Rating
- 41A
- Depth
- 57.4mm
- Dimensions
- (H)32.9 mm x (W)7.5 mm x (D)57.4 mm
- Guarantee
- 1 Year
- Height
- 32.9mm
- Mounting
- DIN Rail
- Packaging Types
- Each
- Product Range
- WAGO TOPJOB S 2006 Series
- Size
- 6 mm²
- Suitable For
- 6.0 mm²
- Unspsc V18
- 39121410
- Unspsc V24
- 39121410
- Voltage Rating
- 800V
- Weight
- 0.01kg
- Width
- 7.5mm
