Eterna IP66 16A Electrical Outdoor Time Delay Switch
Part Code: TLS68EX
Stock Code: 0985-4587
Eterna IP66 16A Electrical Outdoor Time Delay Switch
Part Code: TLS68EX
Stock Code: 0985-4587
Features
- Multi range delay function from 2 seconds to 2 hours
- Incandescent 16A max, fluorescent 6A max, compact fluorescent 3A max, low voltage 3A max
- Multiple accurate time settings using DIP switches and rotary adjuster
- Multi point switching, connect two or more units in parallel
- ABS construction
- IP66 rated
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Eterna
- Colour
- Grey
- Current Rating
- 16A
- Depth
- 70mm
- Dimensions
- (H)110 mm x (W)80 mm x (D)70 mm
- Guarantee
- 1 Year
- Height
- 110mm
- IP Rating
- IP66
- Material
- ABS
- Mounting
- Wall
- Number of Wire Connections
- 4
- Override Switch
- Yes
- Packaging Types
- Each
- Product Range
- Electrical Accessories
- Timer Range
- 2 secs - 2
- Type
- Touch
- Unspsc V18
- 39122208
- Unspsc V24
- 39122208
- Voltage Rating
- 230V
- Weight
- 0.12050kg
- Width
- 80mm
