Vent Axia Centra SELV HT Dual Speed dMEV Fan with Humidistat and Timer
Part Code: 443176
Stock Code: 1075-6546
Vent Axia Centra SELV HT Dual Speed dMEV Fan with Humidistat and Timer
Part Code: 443176
Stock Code: 1075-6546
Features
- Supplied complete with a 443695 SELV transformer
- For bathroom or toilet applications
- Continuous running HT model is automatically boosted by the built-in humidistat
- Or by a switched live input which activates the adjustable timer [5-30 minutes]
- Hour run meter as standard on all lo-carbon humidity controlled Centra fans
- Building Regulations Approved Documents F and L compliant, system 3 continuous mechanical extract
- Recognised in SAP Appendix Q - Low SFP on SAP Q
- Quietest dMEV available
- Discreet, tasteful styling
- Single fan for use in all applications
- IPX4 rated - IPX7 rated [SELV]
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Airflow Cubic Metresper Hour
- 21.6 / 32.4 / 54 m³/h
- Airflow Litresper Second
- 6 / 9 / 15 l/s
- Automatic Shutter
- No
- Colour
- White
- Decibel Rating
- 10.8 / 15.5 / 25.2 dB[A] @ 3 m
- Depth
- 150mm
- Dimensions
- (H)160 mm x (W)160 mm x (D)150 mm
- Ducting Size
- 100mm
- Guarantee
- 5 Years
- Height
- 160mm
- Humidistat
- Yes
- Humidistat Range
- 65 - 95%
- IP Rating
- IPX7
- Mounting
- Wall / Ceiling / Panel / Window
- Operation Type
- Timer + Humidistat
- Packaging Types
- Each
- Power Rating
- 3.2W 2.5W 4.2W
- Product Range
- Lo-Carbon Centra SELV
- Standards
- BS 848
- Suitable For
- Bathroom and Toilet
- Supplied With
- Remote Transformer
- Timer Range
- 3 - 30
- Unspsc V18
- 40101502
- Unspsc V24
- 40101502
- Voltage Rating
- 12V
- Weight
- 0.69000kg
- Width
- 160mm
- Zone Rating
- Zone 1
