Cranford Controls 24V DC 4 Tone Platform Base Sounder White
Part Code: FSA6N
Stock Code: 1100-0632
Cranford Controls 24V DC 4 Tone Platform Base Sounder White
Part Code: FSA6N
Stock Code: 1100-0632
Features
- Produces a high and clear output
- Offers four various tones with selectable override tone and continuously variable volume control
- Allows for rapid installation
- Compatible with the Firesafe range of detectors and most other leading brands
- Cover plate is also available allowing product to be converted into a stand alone sounder
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Colour
- White
- Current Consumption
- 11mA
- Decibel Rating
- 89 dB[A] @ 1 m
- Depth
- 41mm
- Diameter
- 115mm
- Dimensions
- (Dia)115 mm x (W)106 mm x (D)41 mm
- Guarantee
- 1 Year
- IP Rating
- IP21
- Material
- ABS Fire Retardant Plastic
- Number of Tones
- 4
- Operating Frequency
- 800 - 1000Hz
- Packaging Types
- Each
- Product Range
- Conventional Fire Alarm Sounder
- Size
- 35 mm x 106 mm
- Standards
- BS 5839
- Temperature Range
- -20 - +70°C
- Type
- Base Sounder
- Unspsc V18
- 46191505
- Unspsc V24
- 46191505
- Voltage Range
- 8 - 32 V DC
- Volume Control
- Yes
- Weight
- 0.12100kg
- Width
- 106mm
