Wrexham 2.5mm² 4 Core LSF Mineral Insulated Cable Black 500V (100m Coil)
Part Code: 4L2.5LSF/BK/1C
Stock Code: 0005-2603
Wrexham 2.5mm² 4 Core LSF Mineral Insulated Cable Black 500V (100m Coil)
Part Code: 4L2.5LSF/BK/1C
Stock Code: 0005-2603
Features
- Manufactured to BS EN 60702-1:2002 A1:2015
- Cable Type: Mineral Insulated Cable
- Cable Voltage rating: 500V
- Insulation: Compressed Magnesium Oxide
- Conductor: Solid Plain Annealed Copper
- Harmonised [H.S] code 8544.49.95
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Wrexham Mineral Cable
- Cable Diameter Lsf
- 9.8mm
- Colour
- Black
- Conductor Class
- 1
- Conductor Resistance
- 7.41Ω
- Cross Sectional Area
- 2.5mm²
- Current Rating
- 26A
- Dimensions
- (L)100 m
- Guarantee
- 30 Years
- Impedance
- 11.166Ω
- Insulation Material
- Magnesium Oxide (MgO)
- Insulation Type
- Mineral
- Length
- 100m
- Maximum Operating Temperature
- 950°C
- Number of Cores
- 4
- Operating Temperature
- 80°C
- Packaging Types
- Coil
- Previously Known As
- CCM4L2.5/BK
- Product Range
- Fire Resistant Cable
- Sheath
- Low Smoke Zero Halogen (LSZH)
- Standards
- BS5839-1:2017 Enhanced to Clause 26.2, BS EN 50200:2015, BS 8434-2:2003 A2:2009, BS6387:2013 C, W & Z, BS 60331, BSEN 60702-1:2002 A1:2015
- Unspsc V18
- 26121629
- Unspsc V24
- 26121629
- Voltage Rating
- 500V
- Weight
- 0.31420kg
