Schneider Acti9 25A 230V 2 Pole 2 NC Contactor
Part Code: A9C20736
Stock Code: 0112-5184
Schneider Acti9 25A 230V 2 Pole 2 NC Contactor
Part Code: A9C20736
Stock Code: 0112-5184
Features
- Ideal for heating, motor control and lighting loads
- 230V AC coil
- DIN rail mounted
- EN 61095
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Coil Voltage
- 230V AC
- Contact Configuration
- 2 NC
- Current Rating
- 25A
- Depth
- 60mm
- Dimensions
- (H)81 mm x (W)18 mm x (D)60 mm
- Guarantee
- 18 Months
- Height
- 81mm
- Mounting
- DIN Rail
- Number of Modules
- 1
- Number of Poles
- 2 Pole
- Packaging Types
- Each
- Previously Known As
- 15960
- Product Range
- Acti9
- Standards
- EN 61095
- Type
- Contactor
- Unspsc V18
- 39121529
- Unspsc V24
- 39121529
- Voltage Rating
- 230V
- Weight
- 0.11800kg
- Width
- 18mm
