MCG 100A 4 Pole Metal Clad Surface Mount Isolator Switch
Part Code: SMI100-4M
Stock Code: 1462-6429
MCG 100A 4 Pole Metal Clad Surface Mount Isolator Switch
Part Code: SMI100-4M
Stock Code: 1462-6429
Features
- Epoxy coated strong steel construction
- Low smoke and fume paint
- Easy access and switch removal
- Padlockable for added security
- Knockout cable entries
- Switch ratings at AC21
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Cable Entry
- Knockout Cable Entries
- Colour
- Red/Yellow/Grey
- Current Rating
- 100A
- Depth
- 125mm
- Dimensions
- (H)270 mm x (W)215 mm x (D)125 mm
- Finish
- Epoxy Coated
- Guarantee
- 1 Year
- Height
- 270mm
- IP Rating
- IP54
- Lockable
- Yes
- Material
- Steel
- Mounting
- Surface
- Number of Poles
- 4 Pole
- Packaging Types
- Box
- Standards
- IEC/EN 60947-1/3
- Unspsc V18
- 39122217
- Unspsc V24
- 39122217
- Voltage Rating
- 690V
- Weight
- 4.30000kg
- Width
- 215mm
