Kewtech KT65DL 8-in-1 Multifunction Installation Tester
Part Code: KT65DL
Stock Code: 1766-6311
Kewtech KT65DL 8-in-1 Multifunction Installation Tester
Part Code: KT65DL
Stock Code: 1766-6311
Features
- Advanced memory - assigns type of test to results e.g. R2 or R1 + R2 for continuity
- Continuity testing from 0.01Ω - 2000Ω with auto null function
- Insulation resistance testing at 250V, 500V and 1000V from 0.1MΩ - 2000MΩ
- New anti trip technology for full no-trip loop testing from 0.01Ω - 2000Ω
- x ½, x 1 and x 5 tests @ 0° and 180° auto and ramp RCD tests
- RCD test currents of 10mA, 30mA, 100mA, 300mA and 500mA
- Earth resistance tests
- Test button in probe as well as lockdown test button for hands free testing
- Additional LED for warning of high voltage output in insulation test mode
- Selectable touch voltage
- Backlit display
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- 3 Phase Rotation
- Yes
- Ac Voltage Measurement
- 500V AC
- Batteries Included
- Yes
- Battery Level Indicator
- Yes
- Battery Size
- AA
- Battery Type
- Alkaline
- Continuity Check
- Yes
- Continuity Range
- 0.01 Ω - 2000 Ω
- Display Type
- LCD
- Earth Electrode Test
- Yes
- Guarantee
- 1 Year
- IP Rating
- IP54
- Insulation Resistance Measuring Range
- 0.1 MΩ - 2000 MΩ
- Insulation Test Voltage
- 250V / 500V / 1000V
- Loop Impedance Range
- 0.01 Ω - 2000 Ω
- Number of Batteries
- 8
- Packaging Types
- Each
- Product Range
- Multifunction Testers
- Rcd Settings
- ½ / x1 / x5 @ 0° and 180° / Auto and Ramp Tests
- Rcd Test Range
- 10 mA / 30 mA / 100 mA / 300 mA / 500 mA
- Safety Range
- CAT III 500V, CAT IV 300V
- Standards
- EN61010
- Supplied With
- ACC064SP G7 Test Lead with Remote Test Button, ACC065 G7 Test Lead Set, Batteries, Instruction Manual, Certificate of Conformity, KAMP 12 Mains Lead, Test Lead Pouch and Soft Carry Case
- Type
- Multifunction Installation Tester
- Unspsc V18
- 41113681
- Unspsc V24
- 41113681
- Video Url
- https://www.youtube.com/embed/6ji0TWgz3G4
- Weight
- 3.70000kg
