IMO 16A 2 Pole 900V DC Surface Mounting Isolator IP67
Part Code: SI16-PEL64R-2
Stock Code: 2072-5411
IMO 16A 2 Pole 900V DC Surface Mounting Isolator IP67
Part Code: SI16-PEL64R-2
Stock Code: 2072-5411
Features
- Specifically designed for photovoltaic systems
- Lockable rotary handle with the Safelock function [On/Off/Lock]
- Insulated thermoplastic enclosure
- Knife-edge contacts
- Guaranteed arc suppression [3ms typical]
- Built in arc cooling chambers
- Max rated current 85A@1000VDC [acc to DC21B/DC-PV1 for SI55}
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Colour
- Grey/Black
- Current Rating
- 16A
- Depth
- 107mm
- Dimensions
- (H)180 mm x (W)98 mm x (D)107 mm
- Guarantee
- 5 Years
- Height
- 180mm
- IP Rating
- IP67
- Lockable
- Yes
- Material
- Plastic
- Mounting
- Surface
- Number of Poles
- 2 Pole
- Packaging Types
- Each
- Previously Known As
- S116-PEL64R-2
- Product Range
- IMO Solar Range
- Standards
- UL508i, IEC/EN 60947-1, UL 60947-1, IEC/EN 60947-3, UL 60947-4-1, CE, RCM and CCC
- Type
- DC Isolator
- Unspsc V18
- 39122233
- Unspsc V24
- 39122233
- Voltage Rating
- 900V
- Weight
- 0.43000kg
- Width
- 98mm
