Chalmit 138W Zone 2 ExnA LED Wellglass

Part Code: EC2N/16L/LE

Stock Code: 2289-8134

Chalmit 138W Zone 2 ExnA LED Wellglass

Part Code: EC2N/16L/LE

Stock Code: 2289-8134

Delivery

2 In Stock

Free delivery on orders over £50

£5.95 Delivery on orders under £50

Features

  • Instant on crisp white light output
  • Highly energy efficient
  • 120,000 maintenance free hours at 25°C
  • Lower power consumption than HID lamps
  • Low temperature applications to -40°C

Downloads

Specifications

All images and text, © Copyright City Electrical Factors Ltd
All images and text, © Copyright City Electrical Factors Ltd
Atex Classificatio
Ex nA IIC Gc, Ex tc IIIC Dc
Cable Entry
4 x M20
Certification Code
BAS04 ATEX 0393X, IECEx BAS 05.0053X
Colour Temperature
5000 K
Depth
357mm
Diameter
327mm
Dimensions
(Dia)327 mm x (D)357 mm
Fixing Centres
327mm
Frequency
50/60 Hz
Guarantee
1 Year
IP Rating
IP66
Lamp Included
Yes
Lamp Type
LED COB
Lumens Output
15630lm
Material
Aluminium
Mounting
Surface
Operating Temperature Range
-40 - 55°C
Packaging Types
Each
Power Rating
138W
Previously Known As
EC2I/16L/LE
Product Range
Eclipse II LED
Standards
EN 60079-10-1, EN 60079-10-2, EN60079-14
Unspsc V18
39111501
Voltage Rating
120V 254V
Weight
12kg
Zone Rating
Zone 2
