Crompton 12 to 230V AC / DC Multi Function Electronic DIN Rail Timer Relay
Part Code: CCMFMVTS 12-230VAC/DCBP
Stock Code: 2296-3927
Crompton 12 to 230V AC / DC Multi Function Electronic DIN Rail Timer Relay
Part Code: CCMFMVTS 12-230VAC/DCBP
Stock Code: 2296-3927
Features
- 7 popular selectable function settings
- 7 adjustable time ranges from 0.1 seconds to 10 days
- DIN rail or screw mounting
- 12V to 230V 50/60Hz AC/DC supply with power on LED
- 8A resistive single changeover contact with status LED
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Changeover
- Yes
- Colour
- Light Grey
- Compliance
- UKCA, CE
- Current Rating
- 8A
- Depth
- 65mm
- Dimensions
- (H)71.2 mm x (W)17.5 mm x (D)65 mm
- Frequency
- 50/60 Hz
- Guarantee
- 1 Year
- Height
- 71.2mm
- Manual Override
- Yes
- Material
- Plastic
- Minimum Time Settings
- 0.1s
- Mounting
- DIN Rail
- Number of Modules
- 1
- Operating Voltage Range
- 12 - 230V
- Packaging Types
- Pack
- Product Range
- CC Range
- Standards
- IEC/EN 61812-1, IEC/EN 61010-1
- Timer Configuration
- 0.1 sec - 100 hrs
- Unspsc V18
- 39121523
- Unspsc V24
- 39121523
- Weight
- 0.49000kg
- Width
- 17.5mm
