Gewiss 32A 3 Pole Emergency Rotary Isolator Switch IP66 / 67 / 69
Part Code: GW70435P
Stock Code: 2403-3181
Gewiss 32A 3 Pole Emergency Rotary Isolator Switch IP66 / 67 / 69
Part Code: GW70435P
Stock Code: 2403-3181
Delivery
129 In Stock
Free delivery on orders over £50
£5.95 Delivery on orders under £50
Features
- Can be padlockable up to 3 locks in the off position
- Switch disconnectors in insulated enclosure
- With 2 auxiliary contacts option
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Gewiss
- Colour
- Red/Yellow/Grey
- Current Rating
- 32A
- Depth
- 75.5mm
- Dimensions
- (H)150 mm x (W)125 mm x (D)75.5 mm
- Frequency
- 50/60 Hz
- Guarantee
- 1 Year
- Height
- 150mm
- IP Rating
- IP66 / IP67 / IP69
- Lockable
- Yes
- Material
- Insulated
- Mounting
- Surface
- Number of Poles
- 3 Pole
- Operating Temperature Range
- -25 - +60°C
- Packaging Types
- Each
- Product Range
- 70 RT HP
- Unspsc V18
- 39122217
- Voltage Rating
- 415V
- Weight
- 0.618kg
- Width
- 125mm
