Fusebox 16A Single Pole 6kA B Curve MCB
Part Code: MT06B161
Stock Code: 2433-7069
Fusebox 16A Single Pole 6kA B Curve MCB
Part Code: MT06B161
Stock Code: 2433-7069
Delivery
98 In Stock
Free delivery on orders over £50
£5.95 Delivery on orders under £50
Features
- Designed for use with Fusebox 18th edition metal consumer units, garage units and enclosures
- Providing protection against overload and short circuit
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Fusebox
- Current Rating
- 16A
- Depth
- 69.6mm
- Dimensions
- (H)83 mm x (W)17.6 mm x (D)69.6 mm
- Guarantee
- 1 Year
- Height
- 83mm
- Incoming Terminal Capacity
- 16mm²
- Mounting
- DIN Rail
- Number of Modules
- 1
- Number of Poles
- Single Pole
- Outgoing Terminal Capacity
- 16mm²
- Packaging Types
- Each
- Short Circuit Rating
- 6kA
- Standards
- IEC/EN 60898-1
- Tripping Characteristics
- B Curve
- Unspsc V18
- 39121603
- Unspsc V24
- 39121603
- Voltage Rating
- 230V
- Weight
- 0.12kg
- Width
- 17.6mm
