Hager 10 Way Dual 100A RCD High Integrity Metal Clad Consumer Unit with SPD
Part Code: VM910CUSPD
Stock Code: 2552-7718
Hager 10 Way Dual 100A RCD High Integrity Metal Clad Consumer Unit with SPD
Part Code: VM910CUSPD
Stock Code: 2552-7718
Features
- Supplied with a full metal DIN rail and 2 x 100A 30mA RCDs and full complement of earth and neutral terminals along with marking labels, busbar and instructions
- Type 2 SPD fitted
- Conforms to BS EN 61439-3 including Annex ZB [16kA rating]
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Board Configuration
- Configurable
- Current Rating
- 100A
- Depth
- 102.5mm
- Dimensions
- (H)240 mm x (W)400 mm x (D)102.5 mm
- Door Type
- Top Hinged
- Guarantee
- 2 Years
- Height
- 240mm
- IP Rating
- IP2XC
- Incoming Device
- 100A DP Isolator
- Incoming Terminal Capacity
- 50mm²
- Material
- Steel
- Mounting
- Surface
- Number of Modules
- 18
- Number of Outgoing Ways
- 10
- Packaging Types
- Each
- Product Range
- Design 30
- Rcd Rating
- 100A
- Rcd Type
- A
- Standards
- BS EN 61439-3
- Surge Protection Fitted
- Yes
- Tripping Sensitivity
- 30mA
- Unspsc V18
- 39121110
- Unspsc V24
- 39121110
- Voltage Rating
- 230V
- Weight
- 5.3kg
- Width
- 400mm
