Proteus 63A 2 Pole 30mA Type B RCD
Part Code: 63/2/30B
Stock Code: 2562-6871
Proteus 63A 2 Pole 30mA Type B RCD
Part Code: 63/2/30B
Stock Code: 2562-6871
Features
- 2 Pole RCD with Type B filter
- Ensures tripping for residual AC currents, pulsating DC currents and smooth DC currents
- Often used when supplying EV charging points
- This product is no longer available to order online - Please check local store for stock
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Proteus
- Current Rating
- 63A
- Depth
- 74mm
- Dimensions
- (H)85 mm x (W)72 mm x (D)74 mm
- Guarantee
- 1 Year
- Height
- 85mm
- Incoming Terminal Capacity
- 35mm²
- Material
- Polyamide (Nylon) case
- Mounting
- DIN Rail
- Number of Modules
- 4
- Number of Poles
- 2 Pole
- Outgoing Terminal Capacity
- 35 mm²
- Packaging Types
- Each
- Product Range
- Residual Current Devices
- Rcd Type
- B
- Short Circuit Rating
- 6kA
- Standards
- BS EN 61008
- Tripping Sensitivity
- 30mA
- Unspsc V18
- 39121614
- Unspsc V24
- 39121614
- Voltage Rating
- 230V
- Weight
- 0.32000kg
- Width
- 72mm
