Ovia Batten Mounted PIR Occupancy Sensor IP65
Part Code: OVPIR010WH
Stock Code: 2598-9202
Ovia Batten Mounted PIR Occupancy Sensor IP65
Part Code: OVPIR010WH
Stock Code: 2598-9202
Features
- 360° detection
- Suitable for any luminaire with a 20mm cable entry
- 10m detection distance
- Zero cross technology
- IP65 rated
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Class Type
- Class 2
- Colour
- White
- Compliance
- UKCA, CE
- Detection Angle
- 360°
- Detection Range
- 10m
- Dimensions
- (L)136.1 mm x (H)27.6 mm x (W)33.2 mm
- Guarantee
- 5 Years
- Height
- 27.6mm
- IP Rating
- IP65
- Length
- 136.1mm
- Lux Adjustment
- Yes
- Maximum Switching Load
- 1200W - Incandescent, 500W - LED
- Mounting
- Batten
- Packaging Types
- Each
- Product Range
- Controls
- Sensor
- PIR
- Timer Adjustment
- 10 secs - 30 mins
- Unspsc V18
- 39122236
- Unspsc V24
- 39122236
- Voltage Rating
- 230V
- Weight
- 0.08180kg
- Width
- 33.2mm
