MCG Metal Clad IP65 Garage Unit with 63A Type A RCD and 6A and 16A MCB
Part Code: MGU63AT616IP65
Stock Code: 2646-0601
MCG Metal Clad IP65 Garage Unit with 63A Type A RCD and 6A and 16A MCB
Part Code: MGU63AT616IP65
Stock Code: 2646-0601
Features
- Complete with fully fitted and pre-wired 2 pole 63A 30mA Type A RCD device plus 1 x 6A MCB B Curve and 1 x 16A MCB B Curve
- Ferruled cable ends for secure connections
- Fully enclosed metal construction body with drop-down snap shut metal cover
- Raised keyholes for secure easy installation
- Multiple circular cable entry knockouts top and bottom [M25 and M40] plus rear aperture/rounded cable entry
- Finished in white polyester powder coating to RAL9010
- BS EN 61439-3 compliant
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Cable Entry
- Knockouts [M25 and M40]
- Compliance
- UKCA, CE
- Current Rating
- 63A
- Depth
- 100mm
- Dimensions
- (H)220 mm x (W)140 mm x (D)100 mm
- Guarantee
- 1 Year
- Height
- 220mm
- IP Rating
- IP65
- Incoming Device
- 63A 30mA Type A RCD
- Incoming Terminal Capacity
- 35mm²
- Material
- Steel
- Mounting
- Surface
- Number of Modules
- 4
- Number of Outgoing Ways
- 2
- Packaging Types
- Box
- Rcd Rating
- 63A
- Rcd Type
- A
- Surge Protection Fitted
- No
- Surge Protection Ready
- No
- Tripping Sensitivity
- 30mA
- Type
- Garage Unit
- Unspsc V18
- 39121110
- Unspsc V24
- 39121110
- Voltage Rating
- 230V
- Weight
- 1.59500kg
- Width
- 140mm
