Hochiki ESP ALN-EN{WHT) Analogue Optical Smoke Detector White
Part Code: FDHAOW
Stock Code: 2649-1804
Hochiki ESP ALN-EN{WHT) Analogue Optical Smoke Detector White
Part Code: FDHAOW
Stock Code: 2649-1804
Features
- Removable, high performance chamber
- Twin LEDs allow 360 degree viewing, green when polling, red in fire
- Locking mechanism [sensor to base]
- Variable sensitivity
- Electronically addressed
- Pulsing / non-pulsing controlled from panel
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Hochiki
- Colour
- White
- Diameter
- 100mm
- Dimensions
- (Dia)100 mm x (H)38 mm
- Guarantee
- 3 Years
- Height
- 38mm
- Humidity Range
- Up to 95% RH @ 40°C (Non Condensing)
- IP Rating
- IP42
- Led Indication
- Yes
- Material
- Polycarbonate
- Maximum Operating Temperature
- 50°C
- Minimum Operating Temperature
- -10°C
- Mounting
- Surface
- Operating Voltage Range
- 17 - 41V
- Packaging Types
- Each
- Standards
- SIL Level 2 EN:54 Part 7 (G200118)
- Storage Temperature Range
- -30 - 60°C
- Type
- Optical Smoke Detector
- Unspsc V18
- 46191501
- Unspsc V24
- 46191501
- Weight
- 0.1kg
