Hager 24 Way TP+N Type B Distribution Board with 125A Incomer
Part Code: JK124BGSD
Stock Code: 2669-7961
Hager 24 Way TP+N Type B Distribution Board with 125A Incomer
Part Code: JK124BGSD
Stock Code: 2669-7961
Features
- Supplied with factory fitted 125A TP incomer
- Enclosure degree of protection IP3X
- Complies with BS EN 60439-3
- Hanging triangle for easy installations. Simply place a screw in the wall and hang the board. Then fix
- Glazed door gives great aesthetics, especially when sited in public areas and allows for checking of device status through locked doors
- Unique trunking entry, top and bottom, enables quick fitting to trunking without the extra cost in time and materials
- Clear shrouded neutral bar allows for cable installation without removing the shroud
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Busbar Rating
- 125A
- Current Rating
- 125A
- Depth
- 132.5mm
- Dimensions
- (H)1250 mm x (W)465 mm x (D)132.5 mm
- Door Type
- Glazed Door
- Guarantee
- 2 Years
- Height
- 1250mm
- IP Rating
- IP3X
- Incoming Device
- 125A TP Isolator
- Incoming Terminal Capacity
- Earth - M8 Stud, Neutral - 50mm² or M6 Stud
- Lockable
- Yes
- Material
- Steel
- Mounting
- Surface
- Number of Outgoing Ways
- 24
- Packaging Types
- Each
- Product Range
- Invicta 3
- Standards
- BS EN 61439-3
- Unspsc V18
- 39121110
- Unspsc V24
- 39121110
- Voltage Rating
- 230V 400V
- Weight
- 20.5kg
- Width
- 465mm
