Proteus 32A Double Pole 2 Module Bidirectional B Curve 10kA 30mA Type A RCBO
Part Code: 32MRBA
Stock Code: 2707-7785
Proteus 32A Double Pole 2 Module Bidirectional B Curve 10kA 30mA Type A RCBO
Part Code: 32MRBA
Stock Code: 2707-7785
Features
- Double pole device in two module format
- The Proteus RCBO is a combination of a B Curve MCB and a Residual Current Device
- Enables both overcurrent protection and earth fault protection to be provided by a single unit
- This combination allows earth fault protection to be restricted to a single circuit
- Ensures that only the circuit with the fault is interrupted
- Bidirectional
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Proteus
- Bidirectional
- Yes
- Current Rating
- 32A
- Depth
- 66mm
- Dimensions
- (H)83 mm x (W)35 mm x (D)66 mm
- Guarantee
- 10 Years
- Height
- 83mm
- Incoming Terminal Capacity
- 25mm²
- Material
- PBT case
- Mounting
- DIN Rail
- Number of Modules
- 2
- Number of Poles
- Double Pole
- Outgoing Terminal Capacity
- 25mm²
- Packaging Types
- Each
- Product Range
- Proteus RCBO
- Rcd Type
- A
- Short Circuit Rating
- 10kA
- Standards
- BS EN 61009
- Tripping Characteristics
- B Curve
- Tripping Sensitivity
- 30mA
- Unspsc V18
- 39121601
- Unspsc V24
- 39121601
- Voltage Rating
- 230V
- Weight
- 0.21600kg
- Width
- 35mm
