Wrexham 6mm² 3 Core Heavy Duty LSF Mineral Insulated Cable Black (100m Coil)
Part Code: 3H6LSF/BK/C
Stock Code: 2725-0141
Wrexham 6mm² 3 Core Heavy Duty LSF Mineral Insulated Cable Black (100m Coil)
Part Code: 3H6LSF/BK/C
Stock Code: 2725-0141
Features
- Manufactured to BS EN 60702-1:2002 A1:2015
- Cable Type: Mineral Insulated Cable
- Cable Voltage rating: 750V
- Insulation: Compressed Magnesium Oxide
- Conductor: Solid Plain Annealed Copper
- Harmonised [H.S] code 8544.49.95
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Wrexham Mineral Cable
- Cable Diameter Lsf
- 13.2mm
- Colour
- Black
- Conductor Class
- 1
- Conductor Resistance
- 3.08Ω
- Conductor Size
- 6mm²
- Cross Sectional Area
- 6mm²
- Current Rating
- 48A
- Dimensions
- (L)100 m
- Guarantee
- 30 Years
- Impedance
- 4.953Ω
- Insulation Material
- Magnesium Oxide (MgO)
- Insulation Type
- Mineral
- Length
- 100m
- Number of Cores
- 3
- Operating Temperature Range
- -40 - 250°C
- Packaging Types
- Coil
- Product Range
- Fire Resistant Cable
- Sheath
- Low Smoke Zero Halogen (LSZH)
- Standards
- BS EN 60702-1:2002 A1:2015, BS 5839-1:2017 Enhanced to Clause 26.2, BS EN 50200:2015, BS 8434-2:2003 A2:2009, *BS 6387:2013 C, W and Z, BS 8519 and BS 8491 CAT C, BS 60331
- Unspsc V18
- 26121629
- Unspsc V24
- 26121629
- Voltage Rating
- 750V
- Weight
- 0.61470kg
