Lewden Metal Clad Garage Unit with 100A Isolator and 6A and 16A MCB
Part Code: PRO-RGARAGE-MS
Stock Code: 2735-9845
Lewden Metal Clad Garage Unit with 100A Isolator and 6A and 16A MCB
Part Code: PRO-RGARAGE-MS
Stock Code: 2735-9845
Features
- Suitable for garages
- 5 Module enclosure supplied with 100A main switch, 6A and 16A MCBs
- For protection of light and sockets circuits
- 1 x extra module included for the installation of a surge protection device
- Round knockouts
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Lewden
- Cable Entry
- Knockouts [M20 and M25]
- Current Rating
- 100A
- Depth
- 106mm
- Dimensions
- (H)266 mm x (W)136 mm x (D)106 mm
- Guarantee
- 1 Year
- Height
- 266mm
- IP Rating
- IP2XC
- Incoming Device
- 100A DP Isolator
- Material
- Steel
- Mounting
- Surface
- Number of Modules
- 5
- Number of Outgoing Ways
- 3
- Packaging Types
- Each
- Product Range
- PRO
- Supplied With
- 100A Main Switch, 16A and 6A MCBs
- Surge Protection Fitted
- No
- Surge Protection Ready
- Yes
- Type
- Garage Unit
- Unspsc V18
- 39121110
- Unspsc V24
- 39121110
- Voltage Rating
- 230V
- Weight
- 2.05000kg
- Width
- 136mm
