Klein TRMS Auto Ranging Digital Multimeter
Part Code: MM720
Stock Code: 2756-9509
Klein TRMS Auto Ranging Digital Multimeter
Part Code: MM720
Stock Code: 2756-9509
Features
- Multimeter with automatic ranging true root mean square [TRMS] technology for increased accuracy
- Tester measures up to 1000V AC/DC voltage, 10A AC/DC current and 60 MΩ resistance plus temperature, capacitance, frequency, low impedance [LoZ], duty-cycle, test diodes and continuity
- High visibility, reverse contrast display with optical sensor to automatically optimize viewability in dark or bright ambient lighting
- Low impedance [LoZ] mode for identifying and eliminating ghost or stray voltages
- Low battery indicator and easily accessible battery and fuse compartment
- Tough meter built to withstand a 6.6 foot [2m] drop and is rated IP42
- Includes carrying pouch, test leads, thermocouple with adapter, and batteries
- CAT IV 600V Safety Rating
- For use in basic and controlled electromagnetic environments such as residential, business and light-industrial locations
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Ac Current Measurement
- 10A
- Ac Voltage Measurement
- 1000V AC
- Auto Ranging
- Yes
- Battery Level Indicator
- Yes
- Battery Size
- AAA
- Battery Type
- Alkaline
- Capacitance Measurement
- 6000µF
- Compliance
- UKCA, CE
- Continuity Check
- Yes
- Data Hold
- Yes
- Dc Current Measurement
- 10A DC
- Dc Voltage Measurement
- 1000V DC
- Depth
- 47mm
- Dimensions
- (H)176 mm x (W)85 mm x (D)47 mm
- Display Count
- 6000
- Display Type
- LCD
- Frequency Measurement
- 1 Hz - 500 kHz
- Fused
- Yes
- Guarantee
- 2 Years
- Height
- 176mm
- IP Rating
- IP42
- Packaging Types
- Pack
- Resistance Measurement
- 60MΩ
- Safety Range
- CAT IV 600V; CAT III 1000V
- Supplied With
- Carrying Case, Test Leads, Thermocouple, Batteries, and User Manual
- Temperature Range
- -40 - 1000°C
- Type
- Digital Multimeter
- Unspsc V18
- 41113630
- Unspsc V24
- 41113630
- Weight
- 0.40800kg
- Width
- 85mm
