Lewden 32A Single Pole 1 Module B Curve 6kA 30mA Type A Compact RCBO
Part Code: RCBO-B32/30/SPA
Stock Code: 2799-8278
Lewden 32A Single Pole 1 Module B Curve 6kA 30mA Type A Compact RCBO
Part Code: RCBO-B32/30/SPA
Stock Code: 2799-8278
Features
- B Curve RCBO for Lewden consumer units, with C Curve versions also available [sold separately]
- Compact 96mm height increases the available wiring space within the consumer unit
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Lewden
- Current Rating
- 32A
- Depth
- 75mm
- Dimensions
- (H)96 mm x (W)18 mm x (D)75 mm
- Guarantee
- 1 Year
- Height
- 96mm
- Incoming Terminal Capacity
- 16mm²
- Mounting
- DIN Rail
- Number of Modules
- 1
- Number of Poles
- Single Pole
- Outgoing Terminal Capacity
- 16mm²
- Packaging Types
- Each
- Rcd Type
- A
- Short Circuit Rating
- 6kA
- Standards
- BS EN 61009-1
- Tripping Characteristics
- B Curve
- Tripping Sensitivity
- 30mA
- Unspsc V18
- 39121601
- Unspsc V24
- 39121601
- Voltage Rating
- 230V
- Weight
- 0.16500kg
- Width
- 18mm
