Garo 100A TP+N Metal Fused Switch
Part Code: GSF3100N
Stock Code: 2807-5360
Garo 100A TP+N Metal Fused Switch
Part Code: GSF3100N
Stock Code: 2807-5360
Features
- Isolator switch, AC23A allows safe operation even with highly inductive loads [motors etc]
- Powder coated mild steel enclosure with RAL7035 finish
- Padlockable in the "OFF" position and door interlocked in the "ON" position
- 100A fuses included
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Current Rating
- 100A
- Depth
- 200mm
- Dimensions
- (H)400 mm x (W)310 mm x (D)200 mm
- Door Type
- Hinged Door
- Guarantee
- 2 Years
- Height
- 400mm
- IP Rating
- IP55
- Lockable
- Yes
- Mounting
- Surface
- Number of Poles
- Triple Pole and Neutral
- Packaging Types
- Each
- Standards
- EN 60947-3
- Supplied With
- 3 x 100A Fuses
- Terminal Capacity
- 35mm²
- Unspsc V18
- 39121116
- Unspsc V24
- 39121116
- Voltage Rating
- 400V
- Weight
- 11.65kg
- Width
- 310mm
