MK Sentry 40A Single Pole 6kA B Curve MCB
Part Code: H5940S
Stock Code: 0042-6442
MK Sentry 40A Single Pole 6kA B Curve MCB
Part Code: H5940S
Stock Code: 0042-6442
Features
- Trip free mechanism
- Suitable for installation in Sentry consumer units and two or four module enclosures
- Sentry range
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Current Rating
- 40A
- Depth
- 73mm
- Dimensions
- (H)81 mm x (W)18 mm x (D)73 mm
- Guarantee
- 10 Years
- Height
- 81mm
- Incoming Terminal Capacity
- 35mm²
- Mounting
- DIN Rail
- Number of Poles
- Single Pole
- Packaging Types
- Each
- Product Range
- Sentry
- Short Circuit Rating
- 6kA
- Standards
- BS EN 60898
- Tripping Characteristics
- B Curve
- Unspsc V18
- 39121603
- Unspsc V24
- 39121603
- Voltage Rating
- 230V
- Weight
- 0.11000kg
- Width
- 18mm
