Deta 100mm 4" Zone 1 Axial Fan with Timer
Part Code: 4700ZT
Stock Code: 2842-7152
Deta 100mm 4" Zone 1 Axial Fan with Timer
Part Code: 4700ZT
Stock Code: 2842-7152
Features
- Sleek design
- Low energy fans – meet building regulation L1A specific fan power of less than 0.5W/l/s
- Low noise fans – meet building regulation F1 by being under 35dB @ 3m for less noise sensitive rooms
- Over run timers factory set at 15 minutes
- Ideal for through wall applications or with ducting lengths under 2m
- Fans have a one shot thermal fuse
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Deta
- Airflow Cubic Metresper Hour
- 88 m³/h
- Airflow Litresper Second
- 24 l/s
- Colour
- White
- Decibel Rating
- 26 dB[A] @ 3 m
- Depth
- 81mm
- Dimensions
- (H)136 mm x (W)158 mm x (D)81 mm
- Ducting Size
- 100mm
- Guarantee
- 3 Years
- Height
- 136mm
- IP Rating
- IP45
- Maximum Operating Temperature
- 40°C
- Mounting
- Wall
- Operation Type
- Timer
- Packaging Types
- Each
- Power Rating
- 8W
- Product Range
- Ventilation
- Standards
- BS EN 60335-2-80
- Timer Range
- 2 - 30min
- Type
- Zone 1
- Unspsc V18
- 40101502
- Unspsc V24
- 40101502
- Voltage Rating
- 230V
- Weight
- 0.68500kg
- Width
- 158mm
