Fusebox 4 Way Consumer Unit with 100A Main Switch
Part Code: F3004M
Stock Code: 2856-9448
Fusebox 4 Way Consumer Unit with 100A Main Switch
Part Code: F3004M
Stock Code: 2856-9448
Features
- Supplied with a 100A main switch, busbar and DIN rail
- Space for SPD device [sold separately]
- Captive screws now standard on the front cover
- Complete with Circuit ID labels
- F3 series consumer units have upgraded reinforced grommet strip included
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Fusebox
- Current Rating
- 100A
- Depth
- 113mm
- Dimensions
- (H)259 mm x (W)162 mm x (D)113 mm
- Door Type
- Top Hinged
- Guarantee
- 1 Year
- Height
- 259mm
- IP Rating
- IP2XC
- Incoming Device
- 100A DP Isolator
- Incoming Terminal Capacity
- 35mm²
- Material
- Powder Coated Steel
- Mounting
- Surface
- Number of Modules
- 6
- Number of Outgoing Ways
- 4
- Packaging Types
- Each
- Standards
- BS EN 61439-3
- Type
- F3 Series
- Unspsc V18
- 39121110
- Unspsc V24
- 39121110
- Voltage Rating
- 230V
- Weight
- 2.3kg
- Width
- 162mm
