Wago 24V DC 0.5 - 4A 1 Channel Electronic Circuit Breaker
Part Code: 787-3861/004-020
Stock Code: 2875-3762
Wago 24V DC 0.5 - 4A 1 Channel Electronic Circuit Breaker
Part Code: 787-3861/004-020
Stock Code: 2875-3762
Features
- 1 channel 24V DC input voltage adjustable from 0.5 to 4A
- Space-saving ECB with one channel
- Reliably and safely trips in the event of an overload and short circuit on the secondary side
- Enables the use of an economical, standard power supply
- Minimises wiring via two voltage outputs and maximises commoning options on both input and output sides
- Status signal adjustable as single or group message
- Reset, switch on/off via remote input or local switch
- Prevents power supply overload due to total inrush current thanks to time-delayed switching on during interconnected operation
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Wago
- Colour
- Grey
- Depth
- 97.8mm
- Dimensions
- (H)94 mm x (W)6 mm x (D)97.8 mm
- Guarantee
- 1 Year
- Height
- 94mm
- Packaging Types
- Each
- Unspsc V18
- 39122205
- Unspsc V24
- 39122205
- Weight
- 0.05570kg
- Width
- 6mm
