C-Tec Door Monitoring Point with Button Reset
Part Code: NC894DKB
Stock Code: 0017-1199
C-Tec Door Monitoring Point with Button Reset
Part Code: NC894DKB
Stock Code: 0017-1199
Features
- Button reset option
- Isolatable, used to protect doors to generate an alarm on the system
- Requires 1 gang 25mm depth backbox [plastic round cornered or metal flushing box]
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Colour
- Grey
- Compliance
- CE
- Depth
- 35mm
- Dimensions
- (H)87 mm x (W)87 mm x (D)35 mm
- Height
- 87mm
- Humidity Range
- Up to 95% RH (Non Condensing)
- IP Rating
- IP45
- Indication
- Yes
- Material
- Plastic
- Mounting
- Wall
- Operating Temperature Range
- -5 - 40°C
- Packaging Types
- Box
- Product Range
- 800 Series
- Type
- Isolatable Monitoring Point
- Unspsc V18
- 46171604
- Unspsc V24
- 46171604
- Voltage Rating
- 230V
- Weight
- 0.10000kg
- Width
- 87mm
