ABB TF42-1.7 1.3-1.7A Thermal Overload Relay
Part Code: 1SAZ721201R1028
Stock Code: 1960-6195
ABB TF42-1.7 1.3-1.7A Thermal Overload Relay
Part Code: 1SAZ721201R1028
Stock Code: 1960-6195
Features
- Overload protection [trip class 10]
- Phase loss sensitivity
- Temperature compensation from -25 to 60°C
- Adjustable current setting for overload protection
- Automatic or manual reset selectable
- Suitable for three and single-phase application
- Trip-free mechanism
- Status indication
- Stop and test function
- Direct mounting onto block contactors
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Depth
- 70.5mm
- Dimensions
- (H)88.3 mm x (W)45 mm x (D)70.5 mm
- Guarantee
- 1 Year
- Height
- 88.3mm
- Overload Rating
- 1.3 - 1.7A
- Packaging Types
- Each
- Product Range
- TF42
- Standards
- EC/EN 60947-1
- Suitable For
- AF09 - AF38 Contactors
- Unspsc V18
- 39122330
- Unspsc V24
- 39122330
- Weight
- 0.14500kg
- Width
- 45mm
