Crouse-Hinds CEAG VLL Series 58W LED Zone 1 Hazardous Area Linear Light Fitting 5700K
Part Code: CCL2004225AE
Stock Code: 2832-4486
Crouse-Hinds CEAG VLL Series 58W LED Zone 1 Hazardous Area Linear Light Fitting 5700K
Part Code: CCL2004225AE
Stock Code: 2832-4486
Features
- Explosion proof Zone1 linear light fitting
- Suitable for where flammable vapours, gases, ignitable dusts, fibers or flyings are present; indoors or outdoors
- Plus Marine, wet locations and hose-down environments
- Upto 40% energy savings compared to similar fluorescent luminaires
- Rated life of 5 years at 55˚C provides long term, low-maintenance operation
- 4 x M20 entries suitable for through wiring
- Daylight white light [5700K]
- For ambient temperatures from -40°C up to +55°C
- Industry leading lumen efficacy with upto 130 lm/w
- Rugged design for extremely harsh environments, IP66 even under vibration
- Retrofit friendly with optional sliding rail mounting system, allowing brackets to be easily adjusted to existing mounting holes
- Item also known as VLL-7L-57-2/6-220
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Atex Classificatio
- Ex db eb mb IIC T5 Gb, Ex tb IIIC T80°C Db
- Cable Entry
- 4 x M20
- Certification Code
- IECEx NEP 21.0020X, SEV 24ATEX 0708X
- Class Type
- Class 1
- Colour
- Light Grey RAL7035
- Colour Temperature
- 5700 K
- Depth
- 125mm
- Dimensions
- (L)1332 mm x (W)178 mm x (D)125 mm
- Emergency
- No
- Fixing Centres
- 700mm
- Guarantee
- 5 Years
- IP Rating
- IP66
- Lamp Type
- Integrated LED
- Length
- 1332mm
- Lens Colour
- Opal
- Lumens Output
- 7400lm
- Material
- GRP / Polycarbonate
- Mounting
- Surface
- Operating Temperature Range
- -40 - +55°C
- Packaging Types
- Each
- Power Rating
- 58W
- Product Range
- VLL Series
- Unspsc V18
- 39111501
- Unspsc V24
- 39111501
- Voltage Rating
- 110V 240V
- Weight
- 16.54000kg
- Width
- 178mm
- Zone Rating
- Zone 1
