Cudis RO2SNF 16A Double Pole 2 Module Bidirectional B Curve 10kA 30mA Type A RCBO
Part Code: RO2SNF-16B/030A
Stock Code: 2845-5823
Cudis RO2SNF 16A Double Pole 2 Module Bidirectional B Curve 10kA 30mA Type A RCBO
Part Code: RO2SNF-16B/030A
Stock Code: 2845-5823
Features
- Ideal for EV, PV and battery installations plus use in OEM, caravan parks, marinas, and leisure parks
- L and N disconnection
- Bi-directional - line and load can be reversed
- Status indicator
- RCBO’s [Residual Circuit Breaker with Overload] are a combination of an RCD and MCB in one unit
- Enables both over-current protection and earth fault protection to be provided by a single unit
- Allows earth fault protection to be restricted to a single circuit
- Ensures only the circuit with the fault is interrupted
- Fire resistant plastic parts, with high impact resistance
- DIN Rail mounting
- Fork busbar terminal s standard cable clamps
Downloads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Cudis
- Current Rating
- 16A
- Depth
- 78mm
- Dimensions
- (H)82 mm x (W)36 mm x (D)78 mm
- Guarantee
- 5 Years
- Height
- 82mm
- Incoming Terminal Capacity
- 35mm²
- Mounting
- DIN Rail
- Number of Modules
- 2
- Number of Poles
- Double Pole
- Outgoing Terminal Capacity
- 35mm²
- Packaging Types
- Each
- Product Range
- RO2SNF
- Rcd Type
- A
- Short Circuit Rating
- 10kA
- Standards
- BS EN 61009-1
- Tripping Characteristics
- B Curve
- Tripping Sensitivity
- 30mA
- Unspsc V18
- 39121601
- Unspsc V24
- 39121601
- Voltage Rating
- 230V
- Weight
- 0.2kg
- Width
- 36mm
