Elkay Microwave Sensor
Part Code: 380A-1
Stock Code: 1019-6221
Elkay Microwave Sensor
Part Code: 380A-1
Stock Code: 1019-6221
Features
- Sends out an electromagnetic wave over a range of up to 30 metres
- Any disturbance of the frequency from a moving object within the detection zone will activate the unit
- 16A rated regardless of load type
- Adjustable from 2 mins to 2 hours
- Red signal LED
- Lux level/daylight adjustment
- Clip-on front cover to conceal screws
- Adjustment on the sensitivity
- Neutral required
- Option to retrofit into existing system
- Please note: LEVPFCC capacitor will often be required when switching certain types of loads
Specifications
- All images and text, © Copyright City Electrical Factors Ltd
- All images and text, © Copyright City Electrical Factors Ltd
- Brand
- Elkay
- Colour
- White
- Compliance
- CE
- Current Rating
- 16A
- Detection Range
- 30m
- Guarantee
- 6 Years
- Lux Adjustment
- Yes
- Material
- ABS
- Mounting
- Wall / Recessed / Surface
- Number of Wire Connections
- 3
- Packaging Types
- Box
- Re Trigger Function
- Yes
- Sensor
- Microwave
- Standards
- BS EN 60669-2-1:2004+A12:2010
- Suitable For
- Resistive, Incandescent, Fluorescent, Compact Fluorescent and LED Loads
- Timer Range
- 2 - 120min
- Type
- Microwave
- Unspsc V18
- 39122236
- Unspsc V24
- 39122236
- Voltage Rating
- 230V
- Weight
- 0.02800kg
