Moeller DILA-22 24V DC Contactor Relay 2 NO + 2 NC Contacts

Part Code: 276414

Stock Code: 1590-9400

Moeller DILA-22 24V DC Contactor Relay 2 NO + 2 NC Contacts

Part Code: 276414

Stock Code: 1590-9400

Delivery

16 In Stock

Free delivery on orders over £50

£5.95 Delivery on orders under £50

Features

  • Basic devices with positive operation contacts
  • DIN rail or screw mounted
  • DILA -22 Contactor relay cannot be used with 4-pole auxiliary contact module
  • EN 60947

Downloads

Specifications

All images and text, © Copyright City Electrical Factors Ltd
All images and text, © Copyright City Electrical Factors Ltd
Brand
Moeller
Coil Voltage
24V DC
Colour
Grey/Black
Contact Configuration
2 NO + 2 NC
Current Rating Ac1
4A
Dimensions
(H)68 mm x (W)45 mm
Frequency
50/60 Hz
Full Load Current
4A
Guarantee
1 Year
Height
68mm
IP Rating
IP20
Mounting
DIN Rail / Panel
Packaging Types
Each
Product Range
DILA Relays
Standards
IEC EN 60947, UL 508, CSA C22.2 No 14
Unspsc V18
39122331
Voltage Rating
24V
Weight
1.5kg
Width
45mm
